AKG DMM14 UL Reference digital automatic microphone mixer w/LAN interface via Ethernet

Mã sản phẩm: DMM14 UL
Hàng trong kho: Còn hàng

Engineered and made in Germany, the DMM14 U digital automatic microphone mixer is ideal for large meetings and conferences. Its DSP function ensures precise mixing of up to 140 channels by cascading up to 10 DMM14 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM14 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking and routing make the DMM14 U a great fit in a variety of spoken word applications.

Additionally, the UL version offers a LAN interface via Ethernet to enable the control over large distances using, for instance, an AMX control system.

In the ULD version, incorporating a highly sophisticated DANTE chip, all ins are available as direct outs, making it an outstanding tool for broadcast applications, while all outs are also available on the DANTE stream. In total the DMM14 ULD provides 22 free assignable DANTE outs. Additionally, 4 DANTE streams can be used as inputs.

Giá bán: Liên hệ

Engineered and made in Germany, the DMM14 U digital automatic microphone mixer is ideal for large meetings and conferences. Its DSP function ensures precise mixing of up to 140 channels by cascading up to 10 DMM14 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM14 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking and routing make the DMM14 U a great fit in a variety of spoken word applications.

Additionally, the UL version offers a LAN interface via Ethernet to enable the control over large distances using, for instance, an AMX control system.

In the ULD version, incorporating a highly sophisticated DANTE chip, all ins are available as direct outs, making it an outstanding tool for broadcast applications, while all outs are also available on the DANTE stream. In total the DMM14 ULD provides 22 free assignable DANTE outs. Additionally, 4 DANTE streams can be used as inputs.



General Specifications

FinishBlack

Dimensions

Width483 mm (19 in)
Height45 mm (1.77 in)
Depth220 mm (8.66 in)

Audio Output

Max. output level+20 dBu
Dynamics>110 dB
Signal-to-noise ratio (S/N)>90 dB
Min. load impedance<100 Ω
Data format24 Bit
Sample frequency48 kHz

Audio Input

Gain0 dB ... 60 dB
Max. input level+20 dBu
Common mode rejection>70 dB
Dynamics>120 dB
Signal-to-noise ratio (S/N)>90 dB
Input impedance>8 kΩ
Equivalent input noise-127 dBu
Phantom voltage48 V DC
Max. supply current per input10 mA
Infeed resistors2 x 6.8 kΩ
Data format24 Bit
Sample frequency48 kHz

Powering Interface

Input voltage100 ... 240 V AC
Mains frequency50 ... 60 Hz
Max. power intake75 Watt
Output voltages24 V

Application

ConferencingYes
PresentationYes
Sound ReinforcementYes

Engineered and made in Germany, the DMM14 U digital automatic microphone mixer is ideal for large meetings and conferences. Its DSP function ensures precise mixing of up to 140 channels by cascading up to 10 DMM14 U mixers. Two additional stereo audio outputs and one stereo USB offer additional routing options. Due to high signal-to-noise ratio, the DMM14 U also keeps noise from multiple open microphones to a minimum. Numerous DSP functions such as filters, compressor/limiter, ducking and routing make the DMM14 U a great fit in a variety of spoken word applications.

Additionally, the UL version offers a LAN interface via Ethernet to enable the control over large distances using, for instance, an AMX control system.

In the ULD version, incorporating a highly sophisticated DANTE chip, all ins are available as direct outs, making it an outstanding tool for broadcast applications, while all outs are also available on the DANTE stream. In total the DMM14 ULD provides 22 free assignable DANTE outs. Additionally, 4 DANTE streams can be used as inputs.



General Specifications

FinishBlack

Dimensions

Width483 mm (19 in)
Height45 mm (1.77 in)
Depth220 mm (8.66 in)

Audio Output

Max. output level+20 dBu
Dynamics>110 dB
Signal-to-noise ratio (S/N)>90 dB
Min. load impedance<100 Ω
Data format24 Bit
Sample frequency48 kHz

Audio Input

Gain0 dB ... 60 dB
Max. input level+20 dBu
Common mode rejection>70 dB
Dynamics>120 dB
Signal-to-noise ratio (S/N)>90 dB
Input impedance>8 kΩ
Equivalent input noise-127 dBu
Phantom voltage48 V DC
Max. supply current per input10 mA
Infeed resistors2 x 6.8 kΩ
Data format24 Bit
Sample frequency48 kHz

Powering Interface

Input voltage100 ... 240 V AC
Mains frequency50 ... 60 Hz
Max. power intake75 Watt
Output voltages24 V

Application

ConferencingYes
PresentationYes
Sound ReinforcementYes
